How to Specify

To specify your Vari-Dec wetroom, first decide the layout of your Wetroom, including the following:

  • Overall size of the shower area
  • Type of gradient e. one-way or two-way towards the drain
  • Length of the linear drain
  • Is the drain against the wall (Wall Grill) or off the wall (Floor Grill)
  • Single, Double or Triple trap
  • G1 Solid Grill or G3 Stone-Infill Grill

Then simply follow the three step process:

1     Select the required number of Drainage Components and traps

2     Select the required number of Graded Boards

3     Select the required Floor or Wall Grill

Stone infill grill wal option

For example, below is a list of items required

for Layout V4 See Typical Layouts Section:

1 x VARDC Drainage Component*

1 x VARHT Single Horizontal Trap 1 x VARINF Infill Panel*

1 x VARGB-700 700mm x 1200mm Tapered Board* 1 x VARWG-1500 G1 1500mm Wall Grill G1

* Trimmable on-site

1 Drainage Components

IMAGE DESCRIPTION SIZE CODE £ Ex VAT £ Inc VAT
Drainage Component 1200 X 300 mm VARDC 116.64 139.96
Single Horizontal Trap 50mm Waterseal VARHT 41.63 49.96
Single Vertical Trap 50mm Waterseal VARVT 41.63 49.96
Infill Panel 300 x 600 mm VARINF 16.85 20.22

2 Graded Boards

Standard Graded Board 300 x 1200mm VARGB-300 77.79 93.35
Standard Graded Board 500 x 1200mm VARGB-500 111.42 133.71
Standard Graded Board 700 x 1200mm VARGB-700 145.02 174.02
Standard Graded Board 1000 x 1200mm VARGB-1000 182.27 218.72
Standard Graded Board 1200 x 1200mm VARGB-1200 199.85 239.94
Standard Graded Board 1500 x 1200mm VARGB-1500 249.79 299.75
TRIM DETAIL

NM: USE ONE
TILE TRIM PER
GRADED BOARD		 Tile trim for   500mm board 800mm VARTT-500 35.00 42.00
Tile trim for   700mm board 1000mm VARTT-700 35.00 42.00
Tile trim for 1000mm board 1300mm VARTT-1000 42.00 50.40
Tile trim for 1200mm board 1500mm VARTT-1200 42.00 50.40
Tile trim for 1500mm board 1800mm VARTT-1500 42.00 50.40

3 Grill details

  DESCRIPTION CODE G1 SOLID £ Ex VAT £ Inc VAT
graded-08 600mm floor grill VARFG-600G1 145.76 174.91
800mm floor grill VARFG-800G1 181.06 217.27
900mm floor grill VARFG-900G1 181.06 217.27
1000mm floor grill VARFG-1000G1 216.35 259.62
1100mm floor grill VARFG-1100G1 216.35 259.62
1200mm floor grill VARFG-1200G1 242.6 291.11
1300mm floor grill VARFG-1300G1 242.6 291.11
1400mm floor grill VARFG-1400G1 269.75 323.69
1500mm floor grill VARFG-1500G1 269.75 323.69
graded-09 600mm floor grill VARFG-600G3 194.76 233.71
800mm floor grill VARFG-800G3 230.05 276.06
900mm floor grill VARFG-900G3 230.05 276.06
1000mm floor grill VARFG-1000G3 265.35 318.42
1100mm floor grill VARFG-1100G3 265.35 318.42
1200mm floor grill VARFG-1200G3 291.59 349.91
1300mm floor grill VARFG-1300G3 291.59 349.91
1400mm floor grill VARFG-1400G3 318.74 382.49
1500mm floor grill VARFG-1500G3 318.74 382.49
graded-10 600mm wall grill VARWG-600G1 163.86 196.63
800mm wall grill VARWG-800G1 199.16 238.99
900mm wall grill VARWG-900G1 199.16 238.99
1000mm wall grill VARWG-1000G1 234.45 281.34
1100mm wall grill VARWG-1100G1 234.45 281.34
1200mm wall grill VARWG-1200G1 260.7 312.83
1300mm wall grill VARWG-1300G1 260.7 312.83
1400mm wall grill VARWG-1400G1 287.85 345.41
1500mm wall grill VARWG-1500G1 287.85 345.41
graded-11 600mm wall grill VARWG-600G3 212.86 255.43
800mm wall grill VARWG-800G3 248.15 297.78
900mm wall grill VARWG-900G3 248.15 297.78
1000mm wall grill VARWG-1000G3 283.69 340.43
1100mm wall grill VARWG-1100G3 283.69 340.43
1200mm wall grill VARWG-1200G3 309.69 371.63
1300mm wall grill VARWG-1300G3 309.69 371.63
1400mm wall grill VARWG-1400G3 336.84 404.21
1500mm wall grill VARWG-1500G3 336.84 404.21
